Distributed Inference with PyTorch from First Principles

0. Preface

Models keep getting bigger. Even if INT4 quantization squeezes the weights onto a single GPU, inference still has to pay for KV cache and activations, both of which scale with batch size and sequence length. In practice, single-GPU inference quickly hits the VRAM wall. Multi-GPU distributed inference is no longer optional.

The problem is that if you jump straight into Megatron-LM, DeepSpeed, vLLM, or SGLang source code, the engineering layers can bury the core ideas. So this note does the opposite: strip everything down to the bare minimum and rebuild the three canonical inference parallelism strategies directly with PyTorch distributed primitives.

The demo uses:

• a tiny two-layer Linear model
• 2 GPUs
• less than 200 lines of core code

From that, we build and benchmark:

• Data Parallelism (DP)
• Tensor Parallelism (TP)
• Pipeline Parallelism (PP)

Full code: Github vitamin-cuda/torch_dist

Environment:

• PyTorch >= 2.0
• 2 NVIDIA GPUs
• NCCL backend

I recommend using NVIDIA’s NGC PyTorch container if you want the least friction.

1. Distributed Setup and Communication Basics

1.1 Process Group Initialization

import os
import torch
import torch.distributed as dist
def setup_dist(rank, world_size):
    os.environ["MASTER_ADDR"] = "localhost"
    os.environ["MASTER_PORT"] = "29500"
    dist.init_process_group("nccl", rank=rank, world_size=world_size, device_id=rank)
    torch.cuda.set_device(rank)
def cleanup_dist():
    dist.destroy_process_group()

Three terms matter here:

• rank: process id, either 0 or 1 in this demo
• world_size: total number of processes, fixed to 2
• NCCL: NVIDIA's high-performance communication backend for GPU collectives and P2P

1.2 Launching Multiple Processes

import torch.multiprocessing as mp
torch.manual_seed(42)
model = TwoLayerModel(hidden_size)
x = torch.randn(batch_size, hidden_size)
with torch.inference_mode():
    ref = model(x)
mp.spawn(
    run_demo,
    args=(cls, label, world_size, model, x, ref),
    nprocs=world_size,
    join=True,
)

One important detail: create the model and input on CPU in the parent process, then move them to GPU inside each child process. Sharing CUDA state across mp.spawn workers is the wrong mental model and usually ends badly.

1.3 Communication Primitives Used in This Demo

PrimitiveTypePurposeall_gathercollectivegather shards from all ranksall_reducecollectivereduce values across all ranks, then broadcast resultisend / irecvpoint-to-pointasynchronous send and receivebatch_isend_irecvpoint-to-pointsubmit multiple P2P ops in one call

all_gather:
Rank 0: [a] ──┐
              ├──> [[a], [b]] on every rank
Rank 1: [b] ──┘
all_reduce(SUM):
Rank 0: 10 ──┐
             ├──> 30 on every rank
Rank 1: 20 ──┘
isend / irecv:
Rank 0               Rank 1
  │                    │
  ├─── isend ─────────>│
  │<──────── irecv ────┤
  │                    │

2. The Toy Model

class TwoLayerModel(nn.Module):
    def __init__(self, hidden_size):
        super().__init__()
        self.layers = nn.ModuleList(
            [
                nn.Linear(hidden_size, hidden_size, bias=False),
                nn.Linear(hidden_size, hidden_size, bias=False),
            ]
        )
    def forward(self, x):
        x = torch.relu(self.layers[0](x))
        return self.layers[1](x)

I use ModuleList so later we can slice layers cleanly for pipeline parallelism. I also set bias=False so tensor parallelism stays focused on the main weight sharding logic instead of bias bookkeeping.

3. Data Parallelism (DP)

3.1 Core Idea

Each GPU holds a full copy of the model. The batch is split across ranks. Every rank computes on its own shard, then all partial outputs are gathered back together.

Input [B, H]
             │
       ┌─────┴─────┐
       ▼           ▼
┌──────────┐ ┌──────────┐
│  Rank 0  │ │  Rank 1  │
│ full net │ │ full net │
│ Batch 0  │ │ Batch 1  │
└────┬─────┘ └────┬─────┘
     │            │
     ▼            ▼
 [B/2, H]     [B/2, H]
     │            │
     └─────┬──────┘
           ▼
      all_gather
           │
           ▼
       Output [B, H]

3.2 Implementation

class DPModel(nn.Module):
    def __init__(self, model):
        super().__init__()
        self.model = model
        self.world_size = dist.get_world_size()
        self.rank = dist.get_rank()
        self.gathered = None
    def forward(self, x):
        local_batch = x.shape[0] // self.world_size
        start_idx = self.rank * local_batch
        end_idx = (self.rank + 1) * local_batch
        local_x = x[start_idx:end_idx]
        out = self.model(local_x)
        if self.gathered is None:
            self.gathered = [torch.empty_like(out) for _ in range(self.world_size)]
        dist.all_gather(self.gathered, out)
        return torch.cat(self.gathered, dim=0)

What matters:

• each rank only computes its own batch slice
• output buffers are allocated lazily from the real output shape
• all_gather reconstructs the full batch output

For inference, this is the right mental model for DP. For training, classic DistributedDataParallel is a different story: the key communication becomes gradient all_reduce, not output all_gather.

4. Tensor Parallelism (TP)

4.1 Core Idea

Tensor parallelism splits the weights themselves.

• Column Parallel Linear: shard output features
• Row Parallel Linear: shard input features, then all_reduce the partial sums

Column Parallel Linear:
X [B,H]      W [H,H]
                │
        ┌───────┴───────┐
        ▼               ▼
   W_0 [H/2,H]     W_1 [H/2,H]
        │               │
        ▼               ▼
    X @ W_0^T       X @ W_1^T
     [B,H/2]         [B,H/2]
Row Parallel Linear:
X [B,H] ─split─> X_0 [B,H/2]    X_1 [B,H/2]
                    │              │
                    ▼              ▼
               X_0 @ W_0^T    X_1 @ W_1^T
                    │              │
                    └──────┬───────┘
                           ▼
                    all_reduce(SUM)
                           │
                           ▼
                      Output [B, H]

The elegant part is the composition:

• column-parallel layer produces [B, H/2] on each rank
• row-parallel layer naturally consumes exactly that shard
• no communication is needed between the two layers
• only the final all_reduce is required

This is the same structural pattern used in real LLM blocks, especially around QKV projections and output projections.

4.2 Implementation

class ColumnParallelLinear(nn.Module):
    def __init__(self, linear):
        super().__init__()
        rank = dist.get_rank()
        world_size = dist.get_world_size()
        out_per_rank = linear.out_features // world_size
        self.weight = nn.Parameter(
            linear.weight.detach()[
                rank * out_per_rank : (rank + 1) * out_per_rank
            ].clone()
        )
    def forward(self, x):
        return x @ self.weight.t()
class RowParallelLinear(nn.Module):
    def __init__(self, linear):
        super().__init__()
        rank = dist.get_rank()
        world_size = dist.get_world_size()
        in_per_rank = linear.in_features // world_size
        self.weight = nn.Parameter(
            linear.weight.detach()[
                :, rank * in_per_rank : (rank + 1) * in_per_rank
            ].clone()
        )
    def forward(self, x):
        out = x @ self.weight.t()
        dist.all_reduce(out, op=dist.ReduceOp.SUM)
        return out
class TPModel(nn.Module):
    def __init__(self, model):
        super().__init__()
        self.fc1 = ColumnParallelLinear(model.layers[0])
        self.fc2 = RowParallelLinear(model.layers[1])
    def forward(self, x):
        return self.fc2(torch.relu(self.fc1(x)))

If you only remember one thing from this section, remember this: column-parallel + row-parallel is the canonical TP pairing.

5. Pipeline Parallelism (PP)

5.1 Core Idea

Pipeline parallelism splits the model by layers. Activations flow from one rank to the next like a production line.

Time T0:
┌──────────┐    ┌──────────┐
│  Rank 0  │    │  Rank 1  │
│ Layer 0  │    │  idle    │
│ compute  │    │          │
└────┬─────┘    └──────────┘
     │ isend
     ▼
 activation
Time T1:
┌──────────┐    ┌──────────┐
│  Rank 0  │    │  Rank 1  │
│  idle    │    │ Layer 1  │
│          │    │ compute  │
└──────────┘    └────┬─────┘
     ▲               │ isend
     │               ▼
     └── irecv   final output

This is simple to understand, but it comes with a cost: pipeline bubbles.

While rank 0 is busy, rank 1 waits. Then rank 1 is busy, while rank 0 waits. With only two stages, the idle fraction can be painfully obvious, which is exactly why PP often shows worse latency than TP in small demos like this one.

In real systems, people attack the bubble with micro-batching:

• training side: schedules like 1F1B
• inference side: chunked prefill or continuous forward micro-batches

The principle is the same: keep every stage fed.

5.2 Implementation

class PPModel(nn.Module):
    def __init__(self, model):
        super().__init__()
        rank = dist.get_rank()
        world_size = dist.get_world_size()
        self.rank = rank
        self.world_size = world_size
        self.is_first = rank == 0
        self.is_last = rank == world_size - 1
        layers_per_rank = len(model.layers) // world_size
        start_layer = rank * layers_per_rank
        end_layer = (rank + 1) * layers_per_rank
        self.layers = nn.ModuleList(model.layers[start_layer:end_layer])
        self.start_idx = start_layer
        self.total_layers = len(model.layers)
        self.buf = None
    def _send(self, tensor, dst):
        reqs = dist.batch_isend_irecv(
            [dist.P2POp(dist.isend, tensor.contiguous(), dst)]
        )
        for req in reqs:
            req.wait()
    def _recv(self, src):
        reqs = dist.batch_isend_irecv([dist.P2POp(dist.irecv, self.buf, src)])
        for req in reqs:
            req.wait()
        return self.buf
    def forward(self, x):
        if self.buf is None:
            self.buf = torch.empty_like(x)
        if self.is_first:
            out = x
        else:
            out = self._recv(self.rank - 1)
        for i, layer in enumerate(self.layers):
            out = layer(out)
            if self.start_idx + i < self.total_layers - 1:
                out = torch.relu(out)
        if self.is_first:
            self._send(out, self.rank + 1)
            return self._recv(self.world_size - 1)
        elif self.is_last:
            self._send(out, 0)
            return None
        else:
            self._send(out, self.rank + 1)
            return None

5.3 Why batch_isend_irecv Instead of dist.send() / dist.recv()?

Two reasons:

1. NCCL does not support the blocking send / recv API path the way people often expect.
2. batch_isend_irecv is the PyTorch-recommended NCCL P2P interface, and it scales better to real pipeline schedules where one rank may need to post multiple sends and receives without deadlocking.

Even though this demo submits only one op at a time, the wrapper keeps the code aligned with real-world practice.

6. Benchmark

Run:

python test.py

Sample output: (Tested on L20)

==================================================
Demo 0: Single GPU
==================================================
[Single GPU] Output match reference: True, Avg time: 10.009 ms
==================================================
Demo 1: DP
==================================================
[DP] Output match reference: True, Avg time: 5.123 ms
==================================================
Demo 2: TP
==================================================
[TP] Output match reference: True, Avg time: 5.748 ms
==================================================
Demo 3: PP
==================================================
[PP] Output match reference: True, Avg time: 11.032 ms

The exact numbers will vary by GPU and software stack, but the trend is the interesting part:

• DP helps because the batch is split cleanly
• TP helps because compute and parameter storage are partitioned
• PP suffers because the toy example has obvious bubbles and no micro-batch overlap

7. DP vs. TP vs. PP

DimensionDPTPPPWhat is shardeddataparameterslayersModel replicafullpartialpartialMemory footprinthighlowlowMain communicationall_gatherall_reduceisend / irecvCommunication cadenceonce per inferenceonce per TP reduction pointonce per stage handoffBest fitsmaller model, larger batchwide hidden layers, tight latencyvery deep modelsLatency behaviorusually goodusually goodbubble-prone

Practical rule of thumb:

• use DP when the model already fits and you want throughput
• use TP when one layer is too wide for one GPU
• use PP when the model depth forces a layer-wise split

For real LLM serving, these strategies are usually combined rather than used alone:

• TP + PP for giant models
• DP for higher request throughput

During prefill, TP is especially useful for lowering time-to-first-token. During decode, TP also helps distribute the KV cache footprint across multiple GPUs, which is often just as important as splitting the math.

8. Final Notes

This demo is intentionally limited to a single node with 2 GPUs, because the goal is conceptual clarity, not cluster orchestration. In production, the same ideas extend to multi-node setups through torchrun, NCCL environment variables, and usually RDMA-capable networking such as InfiniBand or RoCE.

Understanding the communication pattern is only step one. Once tensors land on a single GPU, the next question is harder and more interesting: how do you push the hardware to its limit with custom kernels?

That is exactly what modern inference systems do. Frameworks like vLLM and SGLang do not stop at distributed scheduling. They also wrap highly optimized custom kernels as PyTorch ops.

If that direction interests you, browse Github vitamin-cuda. This project is full of hand-written CUDA kernels and low-level experiments built for exactly that purpose.
